Mixbach
ZigBee 3.0 smart control for stable and fast communication
Available in 4-gang and 8-gang configurations
High load capacity with independent loop control
Premium metal button design for durability
Compatible with standard 86-type wall box
Suitable for multiple lighting types (LED, incandescent, energy-saving)
Parameter | Specification |
|---|---|
Size (L×H×W) | 86 × 86 × 38.3 mm |
Power Supply | 220V AC (Live & Neutral), 50/60Hz |
Max Load | 800W per loop |
Total Load | ≤ 1200W |
Control Channels | 4-Gang / 8-Gang (4 loop / 8 loop) |
Communication Protocol | ZigBee 3.0 |
Installation Method | Standard 86 wall box, supports side-by-side installation |
Load Type | Incandescent lamp, LED lamp, energy-saving lamp, etc. |
Material | Metal button |
